Used General Electric Frame 6B Gas Turbine Generator

Manufacturer: General Electric
Type: Used
Location: USA

Used General Electric Frame 6B Gas Turbine Generator Details

• GE Model 6541B Gas Turbine
• Duel Fuel Base Rated 41,590 KW
• Water Injected Combustion with Inlet Air Cooled
• Heat Rate at ISO 10,860 BTU/KwH
• 5100 RPM
• Diesel Black Start Engine
• Philadelphia Gear Box with Atomizing Air Compressor, 650 hp, DWG no 334A7220P001, Input 5100 RPM
• Philadelphia Load Gear HP rating 68391, Model S664A 224H0L-A, Input 5094 RPM Output 3600 RPM
• Resorcon Turbine Inlet Air Cooling System
• Side Exhaust to HRSG
• Water Injection Pump and System for Nox Control
• Worthington Natural Gas Compressor Bore 13.0 Stroke 6XH S/N A19288 and Gas Train
• Liquid Fuel Pump and Supply System
• GE TEWAC Generator Rated 46,500 KVA, 13800 V, 3 Phase, 60 HZ, PF: 0.9, 1945 AMPS, 125 V Exciter Volts , Field Amps 778. 3600 rpm
• Mark IV Control System
• GAC with GE VB1 3000 AMP Circuit Breaker
• Sound Enclosure

History:

• Unit Installed 1990, Hot Standby, Shutdown 2020.
• Total Hours 86,704.60, Total Starts 2,466.
• Last Overhaul 2014 , Approx. 598 Hours Since Last Overhaul, Still Installed.
