STX-Niigata 8L22HLX Containerized Power Plant

Type: Used

Condition: Excellent

Location: TBD

Used STX-Niigata 8L22HLX Containerized Power Plant For Sale

Output Capacity: 1.7 MW

Frequency: 50Hz/60Hz

Fuel: Diesel

Note: HFO/MDO, Delivery 12 months

*Confidentiality Agreement Required For Additional Details

STX- Niigata 8L22HLX Engine Design

• The proposed STX- Niigata 8L22HLX engine is four stroke, direct injected, turbocharged and intercooled design.
• Engine shaft output corresponds to 100 % load of the engine at ISO 3046/I-1995(E) conditions.
• The engine is designed for continuous heavy fuel duty and can be started and stopped on heavy fuel oil provided that the fuel is treated and heated to operating temperature.

Engine specification

Model: 8L22HLX

Type: Vertical In-line 4-cycle diesel engines

Combustion System: Direct Injection

Number of cylinders: 8

Cylinder bore: 220 mm

Stroke: 300 mm

Speed: 900 rpm

Compression ratio: 15.58

Rated piston speed: 9.6 m/s

Maximum combustion pressure: 20.4 Mpa

Direction of rotation: Clockwise viewing from flywheel end

Starting System: Air over piston

Cooling System: Fresh-water cooling

Lube oil system: Wet type common bed

Turning System: Ratchet handle system

Turbocharger system: Constant Pressure System
