Caterpillar 3512 Diesel Engine

Manufacturer: Caterpillar

Year of Manufacturing: 2004

Type: Used

Condition: Good

Location: Chittagong, Bangladesh

Caterpillar 3512 Diesel Engine Specifications

Power Rating

• Maximum Power: 1119 kW
• Minimum Power: 761 kW
• Maximum Torque: 6210 Nm @ 1400 rpm
• Rated Speed: 1200-1800 rpm

Emission Standards

• Emissions: Non-Certified

General

• Engine Configuration: V-12, 4-Stroke-Cycle Diesel
• Compression Ratio: 13.0:1
• Bore: 170 mm
• Stroke: 190 mm
• Displacement: 51.8 L
• Aspiration: Turbocharged Aftercooled
• Rotation from Flywheel End: Counterclockwise

Approximate Engine Dimensions

• Length: 2676 mm
• Width: 1704 mm
• Height: 1720 mm
• Weight - Net Dry - Basic Operating Engine Without Optional Attachments: 6078 kg

Important Buyers Notice: All items are Sold As-Is with No Warranty expressed or implied. Items offered for sale may be damaged, inoperable and/or missing parts. You are strongly urged to carefully review each photo and video as well as personally inspect the item before making a decision to purchase. Free Oilfield Quote is not responsible for any missing or damaged equipment, part, item or accessory and shall not be held liable for any damage prior to or during the removal and/or delivery of the equipment. Any and all agreements contrary to the above disclaimer must be in writing and agreed upon up front and prior to any transaction.
