Allweiler Vertical Centrifugal Pump

Manufacturer: Allweiler

Year of Manufacture: 2016

Type: Unused

Condition: Excellent

Location: Houston, Texas

Notes:

• Allweiler-Circorp Vertical Centrifugal Pump Specified for turbine lubrication service, continuous duty.
• Manufactured 2016, still in crate, always warehoused.
• Tech manual included.

Allweiler Vertical Centrifugal Pump Specifications

• Centrifugal Pump No 16001719
• Type NSS80-315-W106-T=2286
• Q = 120 m3/h (528 gpm)
• Head height H = 36 m (118 ft)
• Power p = 16.1 KW (21.6 HP)
• Speed n = 1725 rpm
• Diameter = 313 mm (12.3in)

30 HP 125 Volt DC Baldor motor is extremely unusual, can be easily replaced with conventional AC motor.

 Special Motor Specifications

• 30 HP, 125 VDC, 210 Amps, STAB SHUNT, TEFC, MC3212ATD Frame Spec D32-A000-0019
• Serial No: 66161550004.
