750 HP Mechanical | 105ft X 300K lb Drilling Land Rig

Location: USA

Type: Used

Condition: Excellent

750 HP Mechanical | 105ft X 300K lb Drilling Land Rig Package Details

Rig #1 - 750 HP Mechanical | 105ft-300,000# Static Hook Load Double | Twin F-1000 HP 6 3/4in X 10in Triplex | Hydrill 11in 3,000 psi double rams

Rig #2 - 750 HP Mechanical | 105ft-275,000# Static Hook Load Double | Twin F-1000 HP 6 3/4in X 10in Triplex | Hydrill 11in 3,000 psi double rams

DRAWWORKS

Brewster Model N4-A

Grooved for 1 – 1/8in Drill Line

Parmac SR 22 Single Hydromatic Brake

DERRICK

Superior, 105ft high

10ft 9in Rotary Beam Clearance, 13ft RKB 275,000# Static Hook Load with 8 Lines Mounted on Lee C. Moore Triaxle Trailer

POWER SOURCE

2-Caterpillar C-13 (Diesel) 830 Horsepower

2-Twin Disc Model F-11524-TCIL Torque Converters Two Engine Split Oil Bath Compound

(1) Quincy Model 350 Air Compressors

PUMPS

1-Emsco F-1000 6 – 3/4in x 10in Triplex Powered by Cat C32 with National C-245-64 Torque Converters

1-Emsco F-1000 6 – 3/4in x 10in Triplex Powered by Cat C32 with National C-245-64

Torque Converters Low Pressure Mud Mixing System with Two 5in x 6in Centrifugal Pumps with 60 HP Electric Motors

DRILL STRING

Drill Pipe – 4in OD 14.40# Grade G-105, 4in Full Hole with Hardband

Drill Collars – 6in- 6 – 1/4in OD Slick NC44 with Hardband Kelly – Omsco 5 – 1/4in x 36ft Hex

Pipe Spinner – Varco SS10

Kelly Spinner – International

PREVENTERS

1-GK Hydrill 11in 900 Series Annular wp 3000#

1-NL Shaffer 11in Type LWS 3000# Space Saver Double Rams

1-CPC Closing Unit, (4 Station) 3000psi with 25 HP Electric Motor with CPC Model T10 Triplex Pump

(2) Air Pumps CS-01108, (8) 10 Gallon Bladder Type Bottles Choke Manifold – 5,000 psi 4in x 2in with Two Adjustable Chokes

OTHER EQUIPMENT

Crown Block – Superior (5) 36in Sheaves

Traveling Block – 150 Ton Ideco UTB type, 4 Sheaves Swivel – EMSCO LB200 – 200 Ton

Weight Indicator – Martin Decker Clipper

Rotary – 17 – 1/2in x 44 – 1/4in RT 175

Generators – Two 410KW with 2-C15 CAT Tier 4 @ 626 H.P. each Air Compressors – (2) Sullivan 300-DG-TE Screw Type

Fuel Tank with Lubester – 8000 Gallon

Wireline Unit – Mathey Model GC3-B2 type, .092 Line

Mud Tanks – Two Tank System, Rounded Bottom, 560 Barrels with Electric Agitators Shaker – Derrick 503 Type Linear Motion

Desander – Derrick, (2) 12in Cones with Mission Magnum 5in x 6in Centrifugal Pump with 75 HP Electric Motor Desilter – Derrick, (12) 4in Cones with Mission Magnum 5in x 6in Centrifugal Pump with 75 HP Electric Motor Degasser – Derrick Drilco type

281 Barrel Drill Water Tank

OFI Automatic Driller

Important Buyers Notice: All items are Sold As-Is with No Warranty expressed or implied. Items offered for sale may be damaged, inoperable and/or missing parts. You are strongly urged to carefully review each photo and video as well as personally inspect the item before making a decision to purchase. Free Oilfield Quote is not responsible for any missing or damaged equipment, part, item or accessory and shall not be held liable for any damage prior to or during the removal and/or delivery of the equipment. Any and all agreements contrary to the above disclaimer must be in writing and agreed upon up front and prior to any transaction.
