2013 Service King SK 575 Workover Rig

Type: Never Used

Condition: Excellent

Location: USA

Year: 2013

Model: Service King SK 575

2013 Service King SK 575 Workover Rig Description

Rig Specifications:

• Service Depth: 16,000 Feet
• Workover Depth: 10,000 Feet
• Drilling Depth: 7,000 Feet (with 3 1/2 inch Drill Pipe)

Carrier Specifications:

• Axles: 5
• High Tensile Alloy Wide Flanged Beam
• Front Axles: 20,000# Capacity, Suspension: Spring
• Rear Axles: 46,000# Tandem, Suspension: Walking Beam
• Push Axle: 25,000# Capacity
• Front Tires: 385/65R22.5
• Rear Tires: 11R22.5

Power Train:

• Engine: MTU $1300 T4
• Transmission: 4500 OFS Allison

Main Drum Brakes:

• Diameter: 42 inches
• Width: 12 inches
• Water spray brake cooling

Assist Barrel:

• Diameter: 16 inches
• Width: 38 inches
• Chain: Double 140
• Clutch: 324
• Shaft: 6.60 inches
• LeBus Grooving: 1 inch or optional 1 1/8 inch

Sand Drum Brakes:

• Diameter: 42 inches
• Width: 8 inches
• Barrel: 16 inches
• Width: 43 inches
• Chain: Double 140
• Clutch: 224
• Shaft: 5.90 inches
• Water spray brake cooling
• Capacity: 14,400 Feet 9/16 inch or 11,800 Feet 5/8 inch

Mast Specifications:

• Clear Height: 104 Feet
• Maximum Static Load Capacity:
  • 230,000# with 6 lines
  • 200,000# with 4 lines
  • 250,000# with 6 lines
• Tubing Board Capacity: 110,600#
• Pipe Setback Load
• Rod Board Capacity: 31,208# Static Rod Load
