15 inch A-15-T Hacker Rotary Table For Sale

Location: Winnie, TX

Type: Used

Condition: Good

15 inch A-15-T Hacker Rotary Table Specifications

• Model: A-15-T
• Table Opening (API): 15-1/4 inch Recommended Drilling Depth: 3-1/2 inch DP—8000 ft
• Table Diameter: 37-1/2 inch
• Dims: 56in L x 41in W x 18in H
• Master Bushing: API Taper Weight: 3,400 LBS
• Rated Load Capacity: 140 tons 0 RPM
• Ratio Pinion to Rotary: 3.44
• Pinion Shaft: 3 7/16 inch
• Gear Pitch: 1 3/4 inch
• Pinion Shaft Bearing: Tapered Roller
• Main Table Bearing: Ball Thrust
• Upthrust Bearing: Ball Thrust with Adjustable Nut
• Positive Table Lock: Standard
• Oil Reservoir, Capacity: 6 gals.
• Recommended Drilling Depth - 4 1/2 inch Drill Pipe: 5000 Feet
• Centerline of Table to Centerline of Sprocket: API Centers 22 to 44 inch Or Any Length Specified

Important Buyers Notice: All items are Sold As-Is with No Warranty expressed or implied. Items offered for sale may be damaged, inoperable and/or missing parts. You are strongly urged to carefully review each photo and video as well as personally inspect the item before making a decision to purchase. Free Oilfield Quote is not responsible for any missing or damaged equipment, part, item or accessory and shall not be held liable for any damage prior to or during the removal and/or delivery of the equipment. Any and all agreements contrary to the above disclaimer must be in writing and agreed upon up front and prior to any transaction.
